P-Connect connection gateway for safety devices

all about automation zürich 2024

Produkt teilen:

LinkedIn
Facebook
Twitter
WhatsApp

Beschreibung

The P-Connect connection gateway is a system that allows up to six (6) devices to be connected to a data network. Safety information is exchanged via PROFIsafe extensions. Depending on its configurations, the gateway can transmit signals from two NG or NS series RFID safety switches with lock. The connection is performed safely using PROFIsafe standards. Furthermore, the P-Connect gateway can be connected to a number of devices available in the Pizzato Elettrica catalogue. These include the BN series modular control device units, and AN series handles with integrated signalling LED.

Features:
– Aluminium housing with protection degree IP65;
– Operating temperature -15 °C … +50 °C;
– Connection of safety devices to PROFINET and PROFIsafe networks;
– Quick access to diagnostic data such as internal temperature, gateway supply voltage, or current consumption of the connected devices;
– Plug and Play device that reduces wiring time compared to wiring in the cabinet;
– Multiple P-Connect gateways can be connected in series;
– The 3 integrated signal LEDs provide better diagnostic visualisation in the field;
– Various configurations available;
– P-Connect can be located in areas separated from the connected devices to limit the risk of damage.

Available from the 1st quarter of 2023
